757-343 M8, 4 yollu, 3 kutuplu, M16 konnektörlü LED’ li

757-343 M8, 4 yollu, 3 kutuplu, M16 konnektörlü LED’ li

757-343 M8, 4 yollu, 3 kutuplu, M16 konnektörlü LED’ li

Category

Sensor & Actuator Boxes

Brand

WAGO

Stock code

757-343

*starting from 7,11 USD!

%50 Discount

63,94 USD + VAT

153,46 USD

Transfer

76,73 USD

as Cabinet

Details

technical data

R ON (max.)	0.01Ω
Supply voltage	DC 10 ... 30 V; Rated voltage: 32V ~ eff.
Current carrying capacity of signal connections	2 A
Current carrying capacity of the supply connections	6 a
Nominal value of electrical insulation	500V
Functionally separated potential groups	Contact / Contact
Insulation resistance	1000 MΩ
Signal characteristic	PNP
Indicators	LED yellow: Signal status (1 x per contact); LED (U) green: Sensor / actuator box status

connection data

Connection technology: Inputs / Outputs	4 x M8 connectors, 3-pole
Connection technology: main cable	1 x M16 plug; 14 poles

Geometric Data

Width	30mm / 1.181 inches
Height	26mm / 1,024 inches
Depth	117mm / 4.606 inches

Mechanical Data

Mounting type

screw slot

Material Data

Body material	PA 66 (UL 94 V0); RAL 7035
halogen free	Yes
Material properties of connections	Contact: CuSn, pre-nickeled and 0.8 µm gold plated; Grooved bush: Zn diecast nickel plated; Seal: Viton; Connection loops: 50
Planting	Fully encapsulated with conformal coating (UL 94 V0)

Environmental Requirements

Surrounding air (operating) temperature	-25… 80 °C
Protection class	IP67
Note on Protection Type	Per EN 60529 (NEMA 6 & 6P) in fully locked position with plugs or protective caps
Pollution degree (5)	3 according to VDE 0110
vibration resistant	acc. According to IEC 60068-2-6
Impact resistance	acc. According to IEC 60068-2-27

Commercial Data

Product group	23 (I/O passive and accessories)
Packaging type from SAP	BOX
Country of origin	NIN-NIN
GTIN	4044918978675
Customs Tariff number	85366990990
